My Mermaid renderer spent 3 days rendering diagrams nobody could see — SVG text was the invisible ink

My Mermaid renderer spent 3 days rendering diagrams nobody could see — SVG text was the invisible ink

I built a Mermaid-to-image API that renders flowcharts, sequence diagrams, class diagrams and gantt charts to PNG or SVG, base64-encoded, so agents can turn diagram syntax into shareable images without standing up a headless browser stack. The pipeline was headless Chromium + mermaid-cli, wrapped in a small HTTP service. It worked in my tests. Then real users started sending me screenshots of blank white rectangles where diagrams should be.

The bug was embarrassingly specific to SVG output. PNG rendered fine. SVG came back as a valid file with valid XML and — nothing. Open it in a browser and you'd see empty canvas. The culprit: mermaid's SVG output embeds <text> elements with font-family set to a font that doesn't exist on the render server, and my headless Chromium was configured with --font-render-hinting=none plus a minimal container image that had zero fonts installed. Browsers substitute a fallback font and you see text. Slack, Discord, GitHub previews, most image viewers — they don't. They honor the missing font and render nothing. The text was there in the DOM. It was just invisible.

The fix was two lines in the Dockerfile: install fonts-dejavu-core and set mermaid's fontFamily to a font stack that actually exists on the server (DejaVu Sans, sans-serif instead of the default "trebuchet ms", verdana, sans-serif). After that, SVG output rendered identically everywhere I tested — Slack, Discord, Notion, GitHub comments, email clients.

The deeper lesson: when you render images server-side, you're not just producing pixels — you're shipping a font dependency. PNG rasterizes the text into pixels at render time, so the font only needs to exist on your server. SVG keeps text as text, which means the font has to exist on every machine that displays it. That's a fundamentally different contract. I defaulted new users to PNG after that and made SVG opt-in with a warning in the docs.

If you're building any image or diagram rendering API, test your output in the places it will actually be consumed, not just in a browser on your dev box. "Valid SVG" and "visible diagram" are not the same thing.

I ended up packaging it as https://x402.freeq.one/tools/mermaid.html — flowcharts, sequence diagrams, class diagrams, gantt charts, PNG or SVG, base64 back in one call.
